Description

AR2412 is the Main AudioRack for the GLD digital mixing system.

AR2412 provides 24 XLR inputs and 12 XLR outputs when connected to a GLD-80 or GLD-112 mixer. Connection is over Cat5 cable running Allen & Heath’s dSNAKE protocol, allowing the AR2412 to be positioned up to 120m from the mixer. dSNAKE provides control to the remote preamp, and all mic preamps are scene recallable. For larger systems, an AR84 Expander AudioRack can be connected to the AR2412 to add a further 8 XLR inputs and 4 XLR outputs. AR2412 also includes an Aviom® Pro16 compatible Monitor port.
